Surface treatment intelligence for the people who run tools.

Coatings, nitriding, and surface hardening — explained for the operators, engineers, and reps who actually spec and run treated tools. Interactive tools, deep courses, and a reference where every number traces to a cited source. No metallurgy degree required. No vendor pitch.

Open the PVD ExplorerBrowse the courses

The interactive way in

Don't read a coating spec sheet. Explore it.

Pick a PVD coating and see how its hardness, heat limit, and friction actually compare — as honest ranges, with the sources one click away.

Titanium Nitride

TiN · First-generation monolayer PVD hard coating (gold-colored benchmark)

gold (gold-yellow / metallic gold)
Hardnesshigher = harder2,300HV
range 2,000–3,000medium confidence
Max service temphigher = more heat550C
range 450–600medium confidence
Friction vs steellower = slicker0.6dimensionless
range 0.6 · steel / 100Cr6, dry, unlubricated (ball-on-disc, ASTM G99)medium confidence

Thickness

1–5 um

Deposition temp

400–500 C

Typically chosen for

  • Wear protection on cutting tools (drills, taps, milling cutters, inserts)
  • Forming, stamping and fine-blanking tooling
  • Plastic injection molding components
  • Decorative gold finish and medical/food-contact parts (biocompatible, inert)

These are general process properties for understanding tradeoffs — not a specification for your application. Real selection needs a coating house with your substrate, geometry, and duty data. Values are ranges because real coatings vary by process and supplier; the bright marker is the typical value, the band is the published spread.

Open the full explorer — with notes & sources

Start by topic

Four ways into surface treatment

Coatings (PVD)

Reference + tool

TiN, TiAlN, AlCrN, CrN, ZrN, DLC — the thin-film ceramics. Compare hardness, heat, and friction in the Explorer.

Open

Nitriding

Course

Gas, salt-bath, plasma, FNC — diffusion hardening for tool & die. Spec it, QC it, read the failure modes.

Open

Case hardening

Course

Carburizing, carbonitriding, and the fundamentals of putting a hard case on a tough core.

Open

Die & tooling

Courses

Building and running forge dies — steel selection, treatment sequencing, and keeping a die alive on the floor.

Open

Go deep

Four courses, substrate to surface

  1. 01

    Surface Treating Basics

    A working operator's intro to coatings, heat treatment, and surface hardening for tool-and-die. Vendor-neutral and source-cited.

  2. 02

    Nitriding for Tool & Die

    The deep dive. Twelve lessons on spec'ing, QC'ing, and reading the failure modes of nitrided tooling — gas, salt-bath, plasma, FNC.

  3. 03

    Forge Die Building

    Thirteen lessons on building forge dies from blank stock: die steel selection, cavity design, heat treatment, surface treatment sequencing, and clean vendor handoff. For tool builders and die designers.

  4. 04

    Running Forge Dies

    Thirteen lessons on keeping a die alive on the production floor: pre-heat, lubrication, inspection cadence, diagnostic workflow, maintenance options, and the operator habits that double die life.

Why trust this

Vendor-neutral. Every number cited.

No vendor pitch

We explain the processes and tradeoffs. We don't spec a coating for your part — that needs a real coating house with your data.

Sourced, as ranges

Every value is a cited range, not a marketing number, because real coatings vary. Where sources disagree, we show it.

Archived provenance

Each source is snapshotted and dated, so a claim stays auditable even if the original page changes or disappears.

Take it with you

Get the PDF — or talk to a specialist

Drop your email for the full reference as a PDF. Stuck on a real part that's failing? Tell us what's happening — a person, not a bot, will point you in the right direction.

No spam, no marketing automation. You can unsubscribe anytime.

An AI you can ask about any of this is coming.

Prefer to read offline? Download the full course PDF
